Thermoslide 80
Thermoslide 80 sliding door
User friendly, THERMOSLIDE 80 is a highly-insulated system that can be slid aside without the need to lift.
Have a question about our doors?
One of our glazing experts will be able to answer any questions you have. Sometime it’s easier to speak to someone in the know.
Contact usHave a question about our doors?
One of our glazing experts will be able to answer any questions you have. Sometime it’s easier to speak to someone in the know.
Contact us
About the Thermoslide 80
The highly insulating sliding system is perfectly suited for residential glazing for contemporary homes. Enjoy a safe, warm and cozy environment. Large-scale sliding panels ensure transparency and the best possible view of the surrounding environment. There is an extensive range of configurations available, where all panels can be mobile on up to three tracks or you can park sliding panels behind a static screen or wall. Triple glazing is particularly suited for this highly insulated profile. You can utilise this system where large panels, high heat insulation and inclined thresholds are required to complete your living and working spaces or winter gardens. Panels slide easily and silently on high-quality stainless roller bearings and stainless tracks.
Technical Details
- Panel width
- Max 2700 mm
- Panel height
- Max 2800 mm
- Panel weight
- Max. 350 kg.
- Panel thickness
- Max 80mm
- Glass thickness
- Double glazing or triple glazing can be applied between 24mm-62mm thickness.
- Insulation
- Uf 1.8 W / m².K (Uw 0.8-1.4 values can be obtained with Solar Low-E glass)
Assembly formations
Up to 6 leaves
90 ° corner joints without profile frame glass corner; a fixed and movable panel or option for both movable panels,
It can be mounted to same level as floor by optional connection profile on the inside of the lower rail
Downloads
Service works
Do you have Aluminum products in your home already? such as Bi folding doors, windows and sliding doors, are they not running as smoothly as they should be or have a broken part or lock? get in touch today to give them a new lease of life with a full service or even a repair.
Explore
Led by design
Here at Elements Systems we have the right products for your perfect build. From windows to bi folding doors to aluminum roofs!
Explore
Expert advice
With over 30 years of experience in aluminum products theres nothing our team doesnt know! Please feel free to get InTouch if you have any question about our products.
ExploreYou may also be interested in these doors
Frequently asked quesions
Get in touch with a member of our team today!
lead time is from placing the order once our 'acceptance form' this can between 4-6 weeks.
Yes we do however we do you use recommended installers also.
Not only do you get a 10 year warranty with your new products you get the help and knowledge from our experienced engineers who are always on the end of the phone!
Yes we can offer a standard service to your bi-folding doors , sliding doors and windows to get them operating smoothly again. we also offer repairs to broken products such has hinges, lock mechanisms and replace glazing.
Modern windows have to be well-insulated, durable and easy to care for. Aluminum meets these three requirements perfectly and offers the following additional benefits:
Lightweight, but sturdy and durable. Long life and complete recyclability without reduction in quality. Excellent thermal insulation thanks to thermal separation and airtightness.
